◆ Build in 2*20W stereo digital amplifier
◆ Based on TCP/IP protocol, multi-function pre-player
◆ Support separated running form host and network
◆ Audio source: AUX, 100V line input, MIC, network audio, built-in source
◆ Support large capacity storage, built-in program source
◆ Audio format: MP3, WMA, WAV, FLAC, APE, etc.
◆ MIC sensitivity adjustable, with whistle suppression, echo removal technology
◆ Support remote one-button paging and intercom
-
Parameter
|
Item |
Name |
Specification |
|
Audio input |
MIC Input sensitivity |
10mV |
|
AUX Input sensitivity |
1.0V |
|
100V Input sensitivity |
100V |
|
Internet port |
RJ45 10/100M (support POE ) |
|
Audio output |
Line output |
1.0V |
|
Control interface |
I/O port input |
5-24V DC, photoelectric isolation |
|
I/O port output |
Normal delay input, 30V/1A, AC/DC |
|
RS485 |
19200bps |
|
VDD input |
12-24V |
|
Other |
Power inpput |
Support below three mode:
①100-240V AC; ②12-24V DC; ③POE |
|
Product dimension |
35*125*100mm |
|
Net weight |
0.5Kg |
