Description

• 5.6" TFT touch screen display, easy to operate
• 8*20/40 matrix,8 audio source inputs and 20/40 audio outputs,
• 5 sets of timing programs, each with 500 timing points for a 7-day cycle
• Built-in MP3 /Tuner player and electro-acoustic program sources;
• 20 fire emergency inputs, one fire linkage output.
• Connect to a computer by LAN; can control the host
• One remote paging microphone input
• The volume of 8 input sound sources can be adjusted separately.
• Built-in monitor speakers can monitor each zone with volume control.
• MP3 can be copied with USB interface or directly by PC.
• With 100 meters of wireless remote control
• With One-touch emergency button and EMC Mic

Technical Parameter


Model	M-2120	M-2140
No. of total control zone	20	40
Display screen	5.6" TFT
Control mode	Touch screen/remote control/wireless control
Input sensitivity	250mV(±25mV)
Output	1V(0dBV)
Built-in audio source	MP3, Radio
MP3	Frequency response	20Hz-20kHz
	SNR	85dB
	Dynamic range	90dB
	Harmonic distortion	0.05%
Radio	AM	Sensitivity	52dB
		Receiving range	522kHz-1620kHz
		Transmission band	6KHz
		SNR	35dB
	FM	Sensitivity	26dB
		Receiving range	87.0MHz-108.0MHz
		Transmission band	15KHz
		SNR	75dB
Wireless control	12 unit with control distance within 100-1000m
Frequency response	20Hz-20kHz(±3dB)（individual zone）
SNR	85dB
Crosstalk	70dB
Warning mode selection	Low level is 0V; high level is 5V～24V
Timing power output	PWR1	AC220V/50Hz/500W
	PWR2	AC220V/50Hz/500W
Fuse	Local protection	F1AL
	Power source protection	F10AL
Power source	AC220V（±10%）/ 50Hz
Gross power consumption	22W
Packing size (mm)	（L×W×H）555×460×235
Machine dimension (mm)	（L×W×H）484×360×132
Net weight	9.2kg	9.6kg
Gross weight	11.8kg	12.3kg

• M-2120_M-2140.pdf



Product ID: PB-9810R
