M-2588 250 Zone Remote Paging Station, 250 Zone Intelligent PA System

PA Speaker

Description

◆ 7 inch LCD touch screen control
◆ 1 line audio input (connect the player devices such as a DVD player, tuner, wireless microphone, etc.)
◆ 1 line audio output (connect to amplifier)
◆ Host partition paging function
◆ Built-in bell sound
Specification

Item	Value
Rated output voltage	1.0±0.2V
MIC Input Sensitivity (Output 1V)	50±10mV
MIC distortion (1kHz / 1V)	MIC：≤0.2%
Effective range of MIC gain limits (± 3dB)	100-12000Hz
MIC SNR (30k low pass)	≥68dB
MIC AGC starting control threshold	600±50mV
AUX Input Sensitivity (Output 1V)	300±50mV
AUX distortion (1kHz / 1V)	AUX≤0.2%
AUX SNR (30k low pass)	≥75dB
Effective range of AUX gain limits (± 3dB)	35-20000Hz
AUX dynamic range	≥26dB
Operating voltage range	AC180-240V
Standby power consumption	14.5W
Power supply	AC220V（±10%）/50Hz
Total power consumption	22W
Outer packing size (L × W × H mm)	415×285×160
Machine size (L × W × H mm)	290×180×77
Gross weight	3.4kg
Net weight	2.4kg

Product Reviews

No Reviews For This Product.
