◆ 8 channels Mono and 8 channels MIC input, 2 channel stereo input
◆ High-performance microphone preamplifiers with switchable phantom power
◆ 3-band channel EQ and high-pass filters
◆ Build-in channel compressors
◆ Smooth 60-millimeter faders & Illuminated channel on switches
◆ Bright meters for visual level monitoring
◆ Cabinet mountable
-
Specification
Output power |
35W |
Max output level |
19dBM(1Hz, THD=0.5%) |
Phones output |
40mW(1Hz, THD-0.5%, 200Ω) |
Input type |
XLRx4, RCAx4 |
Frequency response |
20Hz-20KHz |
S/N |
71dB |
T.H.D. |
≤0.05% (1KHz, 0.775V) |
EQ |
LOW: 80Hz±15dB |
MID: 2.5KHz±15dB |
HIGH: 12KHz±15dB |
Gain control |
Mono: -55dB~0dB |
Sereo: -10dB~0dB |
Power supply |
AC220V 50~60Hz |
Dimension(LxWxH) |
483x200x300mm |
Net weight |
6Kg |
