◆ 2 AUX input, 3 MIC input, MIC1 with muting function; 1 AUX out for link
◆ Individual/Master volume control for all inputs, BASS and TREBLE tone control
◆ Output: 70V, 100V, 4~16Ω
◆ LED indicator
◆ Short circuit, overload, high temperature protection
Model |
PB-8070 |
PB-8130 |
PB-8260 |
PB-8360 |
PB-8500 |
Rated output power |
60W |
120W |
240W |
350W |
500W |
Output |
Low impedance |
4-16Ω |
70V |
70Ω |
38Ω |
19Ω |
14Ω |
10Ω |
100V |
143Ω |
77Ω |
39Ω |
28Ω |
20Ω |
AUX output level |
0.775V (0dBV) |
Input level |
MIC 1,2,3 |
600Ω, 10-15mV (unbalanced) |
AUX 1,2 |
10KΩ, 200-470mV (unbalanced) |
Frequencey response |
60Hz-15KHz (±3dB) |
T.H.D. |
<0.5% at 1KHz, 1/3 rated output power |
S/N ratio |
MIC 1,2,3 |
≥72dB |
AUX 1,2 |
≥85dB |
Tone |
Bass |
±10dB at 100Hz |
Treble |
±10dB at 12KHz |
Muting function |
MIC1 overrides other input signals at 0~30dB |
Controls |
Volume, tone/treble, mute, power |
Protection |
AC fuse, Overload, Short circuit, high temperature |
FUSE×4A |
FUSE×4A |
FUSE×6A |
FUSE×6A |
FUSE×8A |
Cooling fan |
DC 12V FAN |
LED indicator |
AC: POWER, level: 2、4、6、8、10 |
Power supply |
AC220~240V, 50-60Hz |
Power consumption |
95W |
185W |
350W |
485W |
675W |
Power cord |
(3×0.75 mm2)×1.5M (standard) |
Product dimension |
89(H)×483(W)×366(D) mm |
Packing dimension |
185(H)×520(W)×435(D) mm |
Net weight |
10.5Kg |
11.5Kg |
13.8Kg |
14.5Kg |
15.5Kg |
Packing weight |
11.80kg |
13.10kg |
15.40kg |
15.80kg |
17.20kg |
